Applications:
- Palm Oil Mill.
- Condensate Fit Pump
- Empty Bunch Press Pump
- Claybath Pump
- Crude Oil Pump
- Sludge Pump
- Sand Cyclone Pump
- Reclaimed Oil Pump
- Oil Recycling Pump
- Sludge Fit to Recovery Tank
- Sludge Fit to Reclimed Oil Tank
- Sludge Recovery tank
- Solid & Sludge Handling.
- Waste Water
- Sewage
- Slurries
- Fat trap
- Crude oil
- Land Application
Product features
- Back Pull Out design for easy maintenance.
- Material (Casing/Impeller/Shaft)
- SSCMA / SSCMA / SS304
- SS304 / SS304 / SS304
- All impeller back vanes to reject solid from water box entering seal housing.
- Grease / oil lubrication
- Vee pulley belt driven or direct couple
- Mechanical Seal SiC vs. SiC faces
Advantages of Victorindo
- Original products from KSB with authorized, Test certificate if required
- Ready stock for new unit and spare parts
- Proven references list in various application especially in Palm Oil Mill application
- Standby service engineer for supervision erection, commissioning & trouble shooting
- Warranty one year
- Training for maintenance & operation teams
- Hassle free; one call for all range of pumps
Operating data
| Technical Data | AQUAFLOW |
| Design | End suction, Semi-open Impeller |
| Pump Size | DN 32 to 100 mm |
| Capacity | Up to 200 m3/hr |
| Head | Up to 80 m |
| Speed | 700 rpm to 3600 rpm |
| Temperature Max. | 120°C |
| Max. Solid size | 50 mm |
